Multisec Steel 3 Column Radiator | White | MHS

Multisec Traditional Steel Column Stocked Radiator | White | MHS

MHS's Multisec Traditional Steel Column Stocked Radiator adds function & elegance to any room. It is finished in RAL 9016 Traffic White as standard and is available in 3 heights, 500mm, 600mm, and 1800mm. The Multisec radiator is available stocked in 2, 3 & 4 columns. Each radiator is supplied with wall brackets and an air vent.

Can't find the right size? Bespoke models with custom widths and more heights are also available here...

Made in Italy from 25mm diameter, 1.2mm steel with 1.5mm headers
Supplied with wall brackets.
Slip-on feet and towel bar are optional extras
Suitable for ½" BSP valves.
5-year manufacturer warranty.
3-5 working day delivery.*

* Delivery Times are subject to change, please get in touch for more accurate lead times. Radiators are delivered kerbside on a pallet.

The Multisec range of steel radiators come with wall brackets included. These are used to fix the radiator to a wall. The radiators can also be made freestanding using either Slip-on feet or Cast feet.

These feet are designed to bear the weight of the radiator and must be used in conjunction with a top retaining stay or other suitable wall fixing to ensure the radiator remains upright.

Height	500mm		Depth	66mm
Sections / Length	BTU Output ∆T 50˚C	Watts Output ∆T 50˚C	BTU Output ∆T 30˚C	Watts Output ∆T 30˚C
6 / 300mm	822	241	446	131
10 / 484mm	1368	401	743	218
13 / 622mm	1778	521	965	283
17 / 806mm	2327	682	1264	370
21 / 990mm	2873	842	1560	457
26 / 1220mm	3559	1043	1933	566
30 / 1404mm	4105	1203	2229	653

Height	600mm		Depth	66mm
Sections / Length	BTU Output ∆T 50˚C	Watts Output ∆T 50˚C	BTU Output ∆T 30˚C	Watts Output ∆T 30˚C
6 / 300mm	966	283	525	154
10 / 484mm	1607	471	873	256
13 / 622mm	2088	612	1134	332
17 / 806mm	2733	801	1484	435
21 / 990mm	3374	989	1832	537
26 / 1220mm	4180	1225	2270	665
30 / 1404mm	4821	1413	2618	767

Height	1800mm		Depth	66mm
Sections / Length	BTU Output ∆T 50˚C	Watts Output ∆T 50˚C	BTU Output ∆T 30˚C	Watts Output ∆T 30˚C
6 / 300mm	2747	805	1492	437
8 / 392mm	3661	1073	1988	583
11 / 530mm	5033	1475	2733	801

**Heat outputs are measured at ∆T 50˚C for newer boilers and shown at ∆T 30˚C, suitable for most heat pumps.

Height	500mm		Depth	107mm
Sections / Length	BTU Output ∆T 50˚C	Watts Output ∆T 50˚C	BTU Output ∆T 30˚C	Watts Output ∆T 30˚C
6 / 300mm	1129	331	613	180
10 / 484mm	1883	552	1022	300
13 / 622mm	2450	718	2450	390
17 / 806mm	3200	938	1738	508
21 / 990mm	3955	1159	2169	629
26 / 1220mm	4896	1435	2659	779
30 / 1404mm	5650	1656	3068	899
35 / 1634mm	6592	1932	3579	1049
40 / 1864mm	7534	2208	4091	1199

Height	600mm		Depth	107mm
Sections / Length	BTU Output ∆T 50˚C	Watts Output ∆T 50˚C	BTU Output ∆T 30˚C	Watts Output ∆T 30˚C
6 / 300mm	1334	391	724	212
10 / 484mm	2225	652	1208	354
13 / 622mm	2893	848	1571	460
17 / 806mm	3780	1108	2053	602
21 / 990mm	4671	1369	2536	743
26 / 1220mm	5783	1695	3140	920
30 / 1404mm	6674	1956	3624	1062
35 / 1634mm	7786	2282	4428	1239
40 / 1864mm	8898	2608	4832	1416

Height	1800mm		Depth	107mm
Sections / Length	BTU Output ∆T 50˚C	Watts Output ∆T 50˚C	BTU Output ∆T 30˚C	Watts Output ∆T 30˚C
6 / 300mm	3688	1081	2003	587
8 / 392mm	4920	1442	2672	783
11 / 530mm	6763	1982	3672	1076

**Heat outputs are measured at ∆T 50˚C for newer boilers and shown at ∆T 30˚C, suitable for most heat pumps.

Height	500mm		Depth	148mm
Sections / Length	BTU Output ∆T 50˚C	Watts Output ∆T 50˚C	BTU Output ∆T 30˚C	Watts Output ∆T 30˚C
13 / 622mm	3211	941	1744	511
17 / 806mm	4200	1231	2281	668
21 / 990mm	5186	1520	2816	825
26 / 1220mm	6421	1882	3487	1022

Height	600mm		Depth	148mm
Sections / Length	BTU Output ∆T 50˚C	Watts Output ∆T 50˚C	BTU Output ∆T 30˚C	Watts Output ∆T 30˚C
13 / 622mm	3757	1101	2040	598
17 / 806mm	4913	1440	2668	782
21 / 990mm	6070	1779	3296	966
26 / 1220mm	7513	2202	4080	1196
30 / 1404mm	8670	2541	4708	1380

**Heat outputs are measured at ∆T 50˚C for newer boilers and shown at ∆T 30˚C, suitable for most heat pumps.

We offer a comprehensive range of accessories to complete your radiator. All radiators come complete with matching wall brackets & a chrome bleed valve. You will require a Valve & Lockshield set & Pipe Shrouds (covers) will finish the look. You can also purchase a bleed valve to match your valve set if you do not want the chrome one.

Click here to view our range or give us a call to discuss your requirements or for a bit of advice.
